XLPE Insulated Cable

محصولات

کابل مشعل جوشکاری

با ما تماس بگیرید

Mr. William

sales1@holdonecable.com

86-- 18724796885

+86 19026815676

حالا تماس بگیرید

XLPE Insulated Cable

مقدار تولیدی:	500 متر
قیمت:	US$ 0.5~56 / meter
بسته بندی استاندارد:	طبل های چوبی
دوره تحویل:	یک هفته یا 10 روز
روش پرداخت:	اعتبارات اسنادی T/T
ظرفیت عرضه:	100 کیلومتر در هفته

جزئیات اطلاعات

توضیح محصول

اطلاعات دقیق

محل منبع

چين

نام تجاری

QINGDAO YICABLE CABLE

گواهی

ISO,CE,IEC,KEMA

نوع مدل:

کابل برق مس ولتاژ کم

رهبر ارکستر:

فلز مس

اندازه ها:

6 ~ 1000 SQMM

هسته:

تنها

عایق:

XLPE

گارانتی:

دو سال

غلاف:

پی وی سی

برجسته کردن:

xlpe electrical cable,cross linked polyethylene cable

cross linked polyethylene cable

توضیح محصول

Copper conductor three core XLPE insulated low smoke halogen-free flame retardant polyolefin sheathed power cable

Applications
This product is applicable to shafts, water and soil, able to bear the larger positive pressure, with power frequency rated voltage of 1kV and below.
For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces.

Application Standards

International: IEC 60502, IEC 60228, IEC60332

China: GB/T 12706 1-2008

Other standards such as BS, DIN and ICEA upon request

Manufacture Standards
International: IEC 60502, IEC 60228, (IEC 60332-3 for FR-type only)
China: GB/T 12706, (GB/T 18380-3 for FR-type only)
Other standards such as BS,DIN and ICEA upon request

Constructions

Code	:	WDZN-YJV23
Standarts	:	TS IEC 60502, IEC 502, VDE 0271, BS 6346
Construction	:	1- Solid, Stranded or Flexible Copper Conductor
		2- XLPE insulation (cross-linked PE) or PVC
		3- PVC inner Sheath or PE, LSOH
		4- Steel Tape Armored
		5- PVC outer sheath, or PE, LSOH
Application	:	Preferably for installation indoors, in cable ducts and in industrial plants or
		switching stations, underground installation with additional protection where
		mechanical damage is unexpected.
Technical Data	:	Max. operating temperature 90 ºC
		Short circuit temperature 250 ºC

Code Designation

YJ : XLPE insulation

V : PVC insulation or sheath

22 : Steel Tape Armored

Technical data

Rated voltage: 0.6/1kv Voltage
PVC Insulation: Maximum Conductor Temperature: under normal (75 ℃), emergency (130℃) or short circuit no more than 5 s (160℃) conditions.

XLPE Insulation: Maximum Conductor Temperature: under normal (90^OC), emergency (130^OC) or short circuit no more than 5 s (250℃) conditions.

Min. Ambient Temp. 0^OC, after installation and only when cable is in a fixed position

Min. Bending Radius: 15 x cable O.D

Certificates

ISO,CE, KEMA ,IEC, RoHS, CCC, P3C and more others at request

PACKING AND SHIPPING

We are capable of meeting the most strict delivery schedules according to per purchase order. Meeting the deadline is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.
Cable is supplied in wooden reels, corrugated boxes and coils. Cable ends are sealed with BOPP self adhesive tape and non-hygroscopic sealing caps to protect the cable ends from moisture. The required marking shall be printed with a weather-proof material on the outsides of drum according to customer's requirement.

Quote Request Information

1. Material of conductor/insulation/sheath.

2. Voltage classes.

3. Cross section, Short circuit current capacity, tension strength.

4. Order Quantity
